文档
当前固件版本: V38
您可以在此找到所有关于 Perdix 3 潜水电脑的重要手册和版本说明。如果您找不到所需内容,请联系我们的客服团队。
- Perdix 3 Manual - English
- Perdix 3 Manual - Japanese
- Perdix 3 Manual - Korean
- Perdix 3 Manual - Simplified Chinese
- Perdix 3 Manual - Thai
- Perdix 3 Manual - Traditional Chinese
- Perdix 3 Release Notes - English
- Perdix 3 Release Notes - French
- Perdix 3 Release Notes - German
- Perdix 3 Release Notes - Italian
- Perdix 3 Release Notes - Simplified Chinese
- Perdix 3 Release Notes - Traditional Chinese
- Perdix 3 Release Notes - Japanese
- Perdix 3 Release Notes - Korean
- Perdix 3 Release Notes - Thai
- Perdix 3 Release Notes - Spanish
- Perdix 3 Release Notes - Portuguese
注意:更新固件将重置减压组织加载。
1. 确保您的移动设备上安装了最新版本的 Dive Shearwater。
2. 在应用程序中,点击连接图标。
3. 如果 Perdix 3 此前已完成配对,将自动连接。如需进行新的连接,请参阅下方蓝牙连接指南。
4. 成功连接后,在应用程序中选择“安装更新” (INSTALL UPDATE)。
支持视频
Perdix 3 蓝牙连接指南
首次通过蓝牙将 Perdix 3 连接到移动设备的操作说明。
将 Perdix 3 与 Dive Shearwater 配对
在移动设备上打开 Dive Shearwater 应用,从底部菜单选择"Connect",然后选择"Add Device"。在 Perdix 3 上,切换至蓝牙菜单,确保蓝牙已开启(显示"On"),然后选择"New Pairing"。
在应用中连接
当 Perdix 3 开始倒计时后,您应该会在应用中看到它出现,选择"Connect"。
确认配对码一致
应用和潜水电脑上都会显示配对码,确认两者一致后,在应用中点击"Pair",在潜水电脑上点击"Connect"。
已成功连接
应用中会弹出窗口询问您是否启用潜水日志自动下载功能。潜水电脑上会显示已连接状态,主屏幕上的蓝牙图标会变为蓝色。完成配对后,只要设备在通信范围内,就会自动连接。
BLUETOOTH FAQ
Common questions and answer for connecting your Perdix 3 to Bluetooth.
We changed the Bluetooth connection process on Perdix 3 to provide significantly faster dive downloads and stronger security. The new pairing flow may feel different from our previous dive computers, but it creates a secure connection between your Perdix 3 and each device you use.
The Perdix 3 can only maintain an active Bluetooth pairing with one Shearwater app at a time. If it is already paired with the Shearwater Cloud mobile app, it will not connect to the Shearwater Cloud Desktop app until it has been disconnected from the mobile app.
No. Once your Perdix 3 has been paired with your phone and the app, it will remain paired and should reconnect automatically whenever you select the Perdix 3 in the connect panel of the app and the dive computer has Bluetooth enabled.
You must remove the previous Perdix 3 connections from the connect panels of the Shearwater applications, from your mobile phone Bluetooth settings, and your PC Bluetooth settings.
常见问题解答
仍有問題?我們有答案.
Perdix 3 在每个潜水模式下都有三种不同的屏幕布局可供选择:Big、Standard 和 Tec。Big 屏幕布局提供最大的字体尺寸,带来最轻松的视觉体验。
标准减压模型是带有梯度因子的 Bühlmann ZHL-16C。未来可能会提供如 DCIEM 等其他算法。
Perdix 3 配备了强大的可自定义振动警报系统。这比声音警报更有效,因为戴头套潜水时声音很难听到,或者在小团队潜水时很难确定是哪台电脑表在发出警报。
没有。Perdix 3 仅提供空气整合版本。
是的。Perdix 3 可以与旧款发射器 (Legacy transmitters) 兼容使用。
没有。Perdix 3 仅为独立使用产品。不过,Perdix 3 配备了闭路循环呼吸器(CC)模式,使用内部固定 PPO2 设定值,可在使用闭路循环呼吸器潜水时计算备用减压方案。如需连接闭路循环呼吸器,Petrel 3 提供 Fischer 和 DiveCAN 型号供选择。
我们强烈建议,如果您长时间不使用 Shearwater 电脑潜水,请取出电池,以避免任何电子设备都可能发生的泄漏和损坏。即使取出电池,您的潜水日志和数据也会安全地存储在电脑上。如果只存放很短的时间,我们建议将 1.5V 锂电池留在设备中,以更好地估算剩余电量。1.5V 碱性电池应始终取出,因为泄漏风险很高。
Shearwater 建议您每 2 年在授权服务中心对您的潜水电脑进行一次保养。
虽然几乎所有类型的 AA 电池都适用于您的 Shearwater Perdix 3,但像 Energizer Ultimate Lithium 这样的 1.5V 锂电池效果最佳。这种类型的电池在很宽的温度范围内表现良好,并且不太可能泄漏并导致您的潜水电脑损坏。在此处阅读更多信息:https://www.energizer.com/about-batteries/battery-leakage
Shearwater does not offer VPM-B unlock codes on newer computers such as Perdix 3 because these products are standardized around Bühlmann ZHL-16C with Gradient Factors. Bühlmann GF is the modern, transparent, widely supported decompression framework used across current Shearwater products, and it gives divers controllable settings for first-stop behavior and shallow-stop conservatism.
VPM-B remains a legacy model associated with older deep-stop bubble-model practice; recent decompression research and expert guidance have increasingly questioned the benefit of deep-stop profiles, and commercial-algorithm validation work found that Bühlmann GF can be tuned to pass proposed validation tests whereas VPM-B could not be tuned to address its too-deep first-stop behavior. For those reasons, adding VPM-B to newer products would create additional testing, support, and documentation burden without a clear evidence-based benefit for most customers.
